Trailblazer Assembly (Texas MUTCD Section 2D.35)

Purpose:
 The Trailblazer Assembly is used at an intersection to indicate the direction to a highway not located at that intersection. Trailblazer Assemblies may also be used at non-intersection locations to direct drivers to the indicated highway.
Components:
 The following components make up a Trailblazer Assembly:
  • Standard:
     TO auxiliary sign, Route sign, Directional Arrow auxiliary sign.
  • Optional:
     Cardinal Direction auxiliary sign.
Figure 3-29 illustrates a Trailblazer Assembly.
Trailblazer Assembly (click in image to see full-size image)
Figure 3-29. Trailblazer Assembly
A Trailblazer Assembly may be incorporated into the Directional Assembly at an intersection as shown in the assembly on the right side of Figure 3-29.
