Section 6: Lane Drop Applications

Lane Drop at No Control Intersections

Figure 7-22 indicates the placement for signing at an intersection approach with no control where there is a lane drop on the through highway.
Lane Drop at Intersection (click in image to see full-size image)
Figure 7-22. Lane Drop at Intersection
