Electrical Service Data

Each electrical service in a plan set should be defined in an electrical service data chart. The data in the chart, combined with Item 628, DMS-11080, and the ED standards gives the contractor enough information to build the exact service equipment required for the project.
Electrical Service Data. The main sectionsof the chart are defined below. (click in image to see full-size image)
Figure 7-1. Electrical Service Data. The main sections of the chart are defined below.
