Rest Area signs (see Figure 3‑9 for examples) provide information about then location of rest areas:

Rest Area signs are addressed in Section 2E.52 of the Texas MUTCD. The provisions in Section 2D.42 of the Texas MUTCD also apply; however, the signs should be suitable for freeway applications. Additional guidance is provided in Chapter 8, Section 5, of the

Signs and Markings Volume

of the

Traffic Operations Manual

.

Rest areas that include tourist information and welcome centers are addressed in Section 2E.53 of the Texas MUTCD.

Placement.

Rest Area Advance signs must be placed 1 or 2 miles in advance of the rest area or at both locations.

Rest Area signs may only be used where parking and restroom facilities are available.

A rest area with parking and picnic tables but no restrooms should be signed PICNIC AREA. Figure 3‑10 provides an example of Picnic Area signs.

A rest area with parking but no restrooms should be signed PARKING AREA.
